A new generation of small outboards.
| MODEL |
DF8A |
|---|
| RECOMMENDED TRANSOM HEIGHT mm |
L: 508 |
S: 381, L: 508 |
|---|
| STARTING SYSTEM |
Electric |
Manual |
|---|
| WEIGHT kg *1 |
L: 46 |
S:39, L:41.5 |
|---|
| ENGINE TYPE |
OHC |
|---|
| FUEL DELIVERY SYSTEM |
Carburetor |
|---|
| NO. OF CYLINDERS |
2 |
|---|
| PISTON DISPLACEMENT cm3 |
208 |
|---|
| BORE ×STROKE mm |
51 X 51 |
|---|
| MAXIMUM OUTPUT kW |
5.9 |
|---|
| FULL THROTTLE OPERATING RANGE rpm |
4,700-5,700 |
|---|
| STEERING |
Tiller |
|---|
| CHOKE |
Electric |
Manual |
|---|
| OIL PAN CAPACITY Lit. |
0.8 |
|---|
| FUEL TANK CAPACITY Lit. |
12 |
|---|
| IGNITION SYSTEM |
Digital CDI |
|---|
| ALTERNATOR |
12V 10A |
12V 6A |
|---|
| ENGINE MOUNTING |
Shear Mount |
|---|
| TRIM METHOD |
Manual Trim and Tilt |
|---|
| GEAR RATIO |
2.08:1 |
|---|
| GEAR SHIFT |
F-N-R |
|---|
| EXHAUST |
Through Prop Hub Exhaust |
|---|
PROPELLER SELECTION (Pitch) *2
All propellers are the 3-blade type |
7"-11" |
|---|
